Aluminum Coil Tube
Temper: O and H14
length: 10ft,20ft,25ft,20ft,50ft etc
max working pressure:4.0Mpa
Processing：Hot extruded
Key Words：
Subclassification：
Aluminum Welding Wire
WhatsAPP：
Product introductionProducts Details
We are a manufacturer of Aluminum Coil Tubing Fuel Line 1/4,3/8,1/2,5/8 and 3/4
Widely used in the automotive and air conditioning industry as important HVAC parts.
Features:
Material alloy grade:1050.1060,1070
Temper: O and H14
Thin wall aluminum tubing
length: 10ft,20ft,25ft,20ft,50ft etc
max working pressure:4.0Mpa
Technical parameter:
Processing：Hot extruded
Pipe Tensible strength: 68-80Mpa
Tube Elongation: 30-40%
Bursting pressure > 1800 PSI
Bending at 1800 by 25mm bending radius: no visible crack.
Surface quality: smooth, no crack
Filling with Ni gas (＞1.00Mpa), keep the pressure for at least 30 minutes,
Checking the pressure gauge with decreasing or not. No leakage is accepted.
Keep pressure in store about 24 hours before delivery
Bending testing:
Bending at 1800 by a 25mm bending radius, there is no visible crack.
Flattening testing:
Pressing tube to be flat (inner wall distance same as wall thickness), no visible crack to be found.
Cleaning test:
Clean the inner wall surface, without any pollution found, total impurity content remained 5~60mg/ m2
Technical data
Chemical Composition:
Various alloy grade aluminum tubing for sale
| 1050 Aluminium Chemical Composition | |||||||||
| Al | Si | Cu | Mg | Zn | Mn | Ti | V | Fe | Others |
| 99.5~100 | 0~0.25 | 0~0.05 | 0~0.05 | 0~0.05 | 0~0.05 | 0~0.03 | 0~0.05 | 0~0.40 | 0~0.03 |
| 1060 Aluminium Chemical Composition | |||||||||
| Al | Si | Cu | Mg | Zn | Mn | Ti | V | Fe | Others |
| 99.6-100 | 0~0.25 | 0~0.05 | 0~0.03 | 0~0.05 | 0~0.03 | 0~0.03 | / | 0~0.35 | |
| 1070 Aluminium Chemical Composition | |||||||||
| Al | Si | Cu | Mg | Zn | Mn | Ti | V | Fe | Others |
| 99.7~100 | 0~0.2 | 0~0.04 | 0~0.03 | 0~0.04 | 0~0.03 | 0~0.03 | 0~0.05 | 0~0.25 | |
Processing technology
1070 alloy aluminum tube is called a hot extruded aluminum tube.
Raw material 1070 aluminum wire rod size 9.5mm, feeding in the hot extruded machinery.
Extrusion model and temperature higher 570 °C aluminum half nearly melting
Aluminum tubing comes through a cold pure water tank to lower surface temperature.
Application:
Refrigerant tube in the HVAC industry
Air conditioner pipe for mini split line set
Automotive repair as fuel lines
Evaporator and condenser pipes
Gas stove connecting pipes
warranty
As one of the top aluminum tube suppliers, we have strict production management and quality control
NO leakage before delivery
Rohs certification environmentally
5 years of quality promise as HVAC parts.
Factory
Hebei Yehui Metal Materials Co., Ltd. was established in 2015, located in Hebei Province, with a factory area of 20000 square meters. We have obtained ISO9001 quality system certification and EU CE certification.
Packing And Delivery
We adhere to the management principle of "quality first, service first, continuous improvement and innovation, and customer satisfaction", with the quality goal of "zero defects, zero complaints". We are pleased to receive your inquiry and will reply as soon as possible.
Application
The main supply fields are: aerospace, national defense equipment, military weapons, chemical industry, shipbuilding, nuclear energy, trains, containers, environmental protection, precision machining, auto parts, machinery, electronic products, molds, medical treatment Equipment, construction, decoration, etc.
Related Products
FAQ
Q1: Are You Manufacture or Trade Company?
A1: We are the professional manufacturer of stainless/carbon/galvanized steel products located in China. Welcome to contact us and visit our factory before you place orders.
Q2: Can I get free samples?
A2: Of course you can. We can produce according to your samples or technical drawings. Contact us by whatsapp or email to get free samples and you will get the sample after 3-7 working days.
Q3: How do you guarantee the quality?
A3: We can send free samples to you, we can accept third-party testing. We also have test certificate, every batch goods will be testing before shipment, and the testing report will delivery to you with your goods.
Q4:How many coutries you already exported ?
A4: Exported to more than 50 countries mainly from Qatar, America, Russia, Belarus, Saudi Arabia, United Arab Emirates, Kuwait, Brazil, Egypt, Turkey, Jordan, India, etc.
Q5:How long is your delivery time?
A5:Within 5 days for stock size, 7-15 working days for customized size.
Q6: Can you OEM or ODM?
A6: Yes, we have a strong developing team. The products can be made according to your request
Q7: What is the MOQ?
A7: If you are scheduling to place a small quantity order or trial order, feel free to contact us, we can meet your requirements.
Q8:What are the certifications for your products?
A8:We have ISO 9001, MTC, third parties' inspections are all available such SGS, BV ect.
